Fronius TPS/i User Manual

Available signals for component scanning
Signal list
WireSense (contour detection):
Signal designation Type of sig-
nal
Data type Factor Value range
WireSense start
(BIT 29)
Input BIT
WireSense break
(BIT 30)
Input BIT
Wire position
(BIT 256-271)
Output
WORD
(SINT) in
mm
100 -327.68 to +327.67
WireSense Edge Detection (edge detection):
Signal designation Type of sig-
nal
Data type Factor Value range
WireSense start
(BIT 29)
Input BIT
Touch signal
(BIT 7)
Output
BIT
(300 ms)
WireSense Edge
Detection (BIT
256-271)
Input
WORD
(UINT) in
mm
10 0 to 20 mm
Wire position
(BIT 256-271)
Output
WORD
(SINT) in
mm
100 -327.68 to +327.67
Teach Mode:
Signal designation Type of sig-
nal
Data type Factor Value range
Teach Mode
(BIT 29)
Input BIT
Wire position
(BIT 256-271)
Output
WORD
(SINT) in
mm
100 -327.68 to +327.67
Touch signal
(BIT 7)
Output
BIT
(300 ms)
63
EN-US
