Information on the Use of the MIG/MAG Standard
Manual, TIG, and Electrode Welding Processes
MIG/MAG Stand-
ard Manual
Use the MIG/MAG standard manual welding process:
1
Select 2-step mode characteristics
2
Select the MIG/MAG standard manual welding process using the appropriate char-
acteristic number
During the standard manual welding process, the wire speed and welding voltage para-
meters are set as follows:
- In order to set the Wire feed speed command value manual parameter, the Wire
feed speed command value analog input signal must be used
- In order to set the Welding voltage command value manual parameter, the Arc
length correction analog input signal must be used
- In order to set the Dynamic correction manual parameter, the Pulse-/dynamic cor-
rection analog input signal must be used
- In order to set the Wire retract correction manual parameter, the Wire retract correc-
tion analog input signal must be used
TIG Use the TIG welding process:
1
Select the TIG welding process using the appropriate characteristic number
Electrode Use the electrode welding process:
1
Select the electrode welding process using the appropriate characteristic number
45
EN-US
