Fronius Data Channel
Fronius Data
Channel
A variety of signals and data can be written and exchanged between the power source
and a control unit (robot controller, etc.) via the Ethernet connection on the rear of the
power source (service port).
In order to be able to use the Fronius Data Channel, OPT/i Documentation must be
enabled for the power source.
On TWIN systems, the Ethernet connection socket on the power source of process line 1
must be used.
Available signals and data:
Number Designation Description Type of signal
1 Process active 1/0 Output
2 Current flow 1/0 Output
3 Article number String Input
4 Serial number String Input
5 Seam number Integer Input
Windows example (PuTTY)
A TCP socket connection must be estab-
lished for data transfer.
1
For this purpose, enter the IP address
of the power source service port and
the port number 4714.
48
