Command value
out of range (Set
value out of
range) - Single
Bit
This signal indicates that the „Wire feed speed command value“ input is outside of the
possible range.
The signal is High if, for example:
- The possible range is limited by the wirefeeder:
• Selected wire speed set value = 25 m/min
• Maximum wire speed set value based on characteristic = 25 m/min
• Maximum possible speed of the wirefeeder = 15 m/min
- The possible range is limited by the characteristic:
• Selected wire speed set value = 25 m/min
• Maximum wire speed set value based on characteristic = 15 m/min
• Maximum possible speed of the wirefeeder = 30 m/min
Additional information for TWIN systems:
The signal is set as soon as one of the two process lines exceeds a defined range.
Correction out of
range (Correction
out of range) -
Single Bit
This signal indicates that at least one of the selected corrections (for example, Arc length
correction) is outside of the specified range.
Additional information for TWIN systems:
The signal is set as soon as one of the selected corrections exceeds the defined range.
Process Bit (Pro-
cess bit) - Group
Output
These signals indicate which welding process has been selected.
Value range for welding process:
Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Description
0 0 0 0 0 No internal mode selection or process
0 0 0 0 1 MIG/MAG pulsed synergic
0 0 0 1 0 MIG/MAG standard synergic
0 0 0 1 1 MIG/MAG PMC
0 0 1 0 0 MIG/MAG LSC
0 0 1 0 1 MIG/MAG standard manual
0 0 1 1 0 Electrode
0 0 1 1 1 TIG
ExtOutput 1-8
(External output
1-8) - Single Bit
Outputs used to control options, such as OPT/i RI FB REL.
- Max. voltage = DC 113 V / AC 68 V
- Max. current load 2 A
Example outputs: ExtOutput1 = OPT_Input 1
32
