If there is no sensor in the system, the signal is set to High.
Additional information for TWIN systems:
The signal is output separately for both process lines.
Sensor Status 2
(sensor status 2)
- Single Bit
This signal indicates the status of the wire end option 4,100,879,CK.
Signal level Description
High Wire electrode present
Low No wire electrode present
The signal is output as soon as the sensor of the option is detected in the system.
If there is no sensor in the system, the signal is set to High.
Additional information for TWIN systems:
The signal is output separately for both process lines.
Sensor Status 3
(sensor status 3)
- Single Bit
This signal indicates the status of the wire end option 4,100,878,CK.
Signal level Description
High Wire electrode present
Low No wire electrode present
The signal is output as soon as the sensor of the option is detected in the system.
If there is no sensor in the system, the signal is set to High.
Additional information for TWIN systems:
The signal is output separately for both process lines.
Wire stick work-
piece (Wire stick
workpiece) -
Single Bit
The signal is High if a wire stick is detected on the workpiece. This signal is always out-
put regardless of other settings.
Additional information for TWIN systems:
The signal is set to High as soon as one of the two wire electrodes sticks.
Parameter selec-
tion internally
(Internal para-
meter selection) -
Single Bit
This signal indicates whether the parameter selection has been set to "internal".
This setting can be applied:
- Using the Working mode signal/internal parameter selection or
- On the power source itself: Defaults/Interface setup/Welding parameter.
34
