Signal Transmis-
sion Time
TPS/i
t
t
TPS/i
<10 ms
Welding start
Process active
Representation of the signal transmission time; the signals shown are for illustrative purposes only
Safety
WARNING!
Danger from incorrect operation and work that is not carried out properly.
Serious personal injury and damage to property may result.
▶
All the work and functions described in this document must only be carried out by
trained and qualified personnel.
▶
Read and understand this document.
▶
Read and understand all the Operating Instructions for the system components,
especially the safety rules.
6
