244

10 Installing Optional Accessories

10. Press the <Power/Power Saver> button to turn on the machine.

Note



When the storage (optional) installation is complete, change the printer configuration under the printer driver properties.

For the change method, refer to "Configuring Options in the Print Driver" (P.29).
