11 Appendix
Punching
Number of punches: 2 holes/4 holes or 2 holes/3 holes (US standards)
Paper sizes for punching: A3, 11 × 17", JIS B4
*2
, A4
*1
, A4 , Letter
*1
, Letter , JIS B5
*1
, JIS B5
*2
, A5
*1
, A5
*1
*1 : 3 holes/4 holes cannot be used.
*2 : 4 holes cannot be used.
Paper weight: 52 to 220 gsm
Important
The punch feature requires the optional 2/4 Hole Punch Kit for Finisher-B3 or US 2/3 Hole Punch Kit for Finisher-B3.
Booklets/double folding
Maximum number of sheets:
Booklets: 15 sheets, double folding: 5 sheets
Paper size:
Maximum: A3, 11 × 17"
Minimum: A4, Letter
Paper weight:
Booklet: 64 to 80 gsm , double folding: 64 to 105 gsm
Important
The optional Booklet Maker Unit for Finisher-B3 is required to use the booklets/creasing feature. Paper is creased to make
it easier to fold. After output specifying booklets or double folding, the next job is not output if the paper in the tray is not
removed. In addition, paper is not ejected if paper is not removed from the tray in the case of output that specified a
small size and booklets or creasing.
Booklet covers can be selected up to a maximum of 220 gsm (extra heavyweight).
Size and weight
592 (W) × 653 (D) × 1041 (H) mm, 25 kg
592 (W) × 673 (D) × 1079 (H) mm, 35 kg (when Booklet Maker Unit is installed)
Important
Values exclude the connection section stored in this machine.
Dimensions occupied during connection with main unit
1645 (W) × 723 (D) mm
When Booklet Maker Unit is installed: 1645 (W) × 723 (D) mm
Important
Main unit plus Finisher-B3 when extension tray is pulled out and bypass tray is at maximum extension.
C3 Finisher with Booklet Maker (optional)
Important
C3 Finisher with Booklet Maker is only available when the optional 2 Tray Module or Tandem Tray Module is installed.
Tray type
Output Tray: Collation /Stacking
Finisher tray: Collation (can be offset) / Stacking (can be offset)
Booklet tray: Collation/Stacking
Paper size
Output tray
Maximum: 12 × 19” (305 × 483 mm)
