6.5 List of Messages
230
Troubleshooting
6
Open G Open 4b toLeft Pull
out4
↓↑
Remove All PaperInside 4
Cause: A paper jam has occurred inside the finisher.
*These messages are displayed alternately.
Action: Open the finisher front cover (G), open [4b] leftward, pull out
unit [4], and wholly remove the paper jammed inside [4].
“6.2.8 Paper Jams in the Finisher”(P.205)
Jam - Open G. Open 4b to
Left
Cause: A paper jam has occurred inside the finisher.
Action: Open the finisher front cover (G), open [4b] leftward and
remove the jammed paper.
“6.2.8 Paper Jams in the FinisherÅ”(P.205)
Open G. Push 4 in. Cause: Unit [4] of the finisher is not fully inserted.
Action: Open the finisher front cover (G), and push in unit [4] fully.
Open G Pull out4Turn 4a to
Left
↓↑
Remove All PaperInside 4
Cause: A paper jam has occurred inside the finisher.
The messages are displayed alternately.
Action: Open the finisher front cover (G), draw out unit [4], turn [4c]
counterclockwise to wholly remove the jammed paper inside
unit [4].
“6.2.8 Paper Jams in the Finisher”(P.205)
"Open G. Add Staples to
R1
Cause: No staple remains in the staple cartridge (R*) of the finisher.
Action: Replace with a new staple cartridge.
“5.5.5 Replacing the Staple Cartridge”(P.146)
“5.5.6 Replacing the Staple Cartridge for Saddle Stitch”(P.148)
Open G. Check Staples in
R2,R3
Cause: Staple cartridges (R2) and (R3) for pamphlets in the finisher
are not set correctly.
Action: Open the finisher front cover (G), and set the staple car-
tridges for pamphlets of the finisher correctly.
“3.1 Main Components and Their Functions”(P.30)
“5.5.6 Replacing the Staple Cartridge for Saddle Stitch”(P.148)
Open G. Add Staples to
R2,R3
Cause: No staple remains in the staple cartridge (R2) or (R3) for
pamphlets of the finisher.
Action: Replace with a new staple cartridge.
“5.5.6 Replacing the Staple Cartridge for Saddle Stitch”(P.148)
Message Cause/action
To Next Page
