Installing the ETSI DCM (SFD6) Shelf
4-31
FLASHWAVE 7500 Release 6.1
Equipment Installation
Fujitsu and Fujitsu Customer Use Only
FNC-7500-0061-200
Issue 1, May 2009
Figure 4-14: ETSI DCM (SFD6) Shelf
Optical Output
Optical Input
DCM Shelf
Cover
Thumbscrews
Cover Removal/Replacement
DCM Unit
Unit Removal/Replacement
