CHAPTER 2
Core Configuration
Installing Cables
2-77
FLASHWAVE 7500 Release 6.1
Equipment Installation
Fujitsu and Fujitsu Customer Use Only
FNC-7500-0061-200
Issue 1, May 2009
Table 2-10: RICC Connections from OS1 to OSn (Core Configuration)
From To
Shelf Port Connector Label Shelf Port Connector Label
OS1 (Main) OS1-12-PC1 CN32 PORT1 OS2 (Auxiliary) OS2-12-PC1 CN32 PORT1
OS1-12-PC2 CN33 PORT2 OS2 (Auxiliary) OS2-10-PC1 CN35 PORT1
OS1-12-PC3 CN34 PORT3 OS3 (Auxiliary) OS3-12-PC1 CN32 PORT1
OS1-12-PC4 CN24 PORT4 OS3 (Auxiliary) OS3-10-PC1 CN35 PORT1
OS1-12-PC5 CN25 PORT5 OS4 (Auxiliary) OS4-12-PC1 CN32 PORT1
OS1-12-PC6 CN26 PORT6 OS4 (Auxiliary) OS4-10-PC1 CN35 PORT1
OS1-10-PC1 CN35 PORT1 OS2 (Auxiliary) OS2-12-PC2 CN33 PORT2
OS1-10-PC2 CN36 PORT2 OS2 (Auxiliary) OS2-10-PC2 CN36 PORT2
OS1-10-PC3 CN37 PORT3 OS3 (Auxiliary) OS3-12-PC2 CN33 PORT2
OS1-10-PC4 CN28 PORT4 OS3 (Auxiliary) OS3-10-PC2 CN36 PORT2
OS1-10-PC5 CN29 PORT5 OS4 (Auxiliary) OS4-12-PC2 CN33 PORT2
OS1-10-PC6 CN30 PORT6 OS4 (Auxiliary) OS4-10-PC2 CN36 PORT2
