Adjustment buttons
- Adjust with the [+] and [-] but-
tons.
- Return to the initial value by
tapping the [reset] buttons.
Mixing amount (Rudder to Flap)
-100~+0~+100
Initial value: +100
Mixing amount (Flap to Rudder)
-100~+0~+100
Initial value: -100
124
Function
Tilt Mixing
3
(Flap rate check and adjustment)
Tap the value button of the "Flap", value input buttons appear
on the screen, and use the [+] and [-] buttons to adjust the
fl aps rate amount.
4
(Rudder to Flap mixing amount adjustment)
Tap the value button of the "Rudder to Flap", Value input but-
tons appear on the screen, and use the [+] and [-] buttons to
adjust the mixing amount.
"+" :Operate in same direction as steering
"-" :Operate in opposite direction of steering
5
(Flap to Rudder mixing amount adjustment)
Tap the value button of the "Flap to Rudder", Value input but-
tons appear on the screen, and use the [+] and [-] buttons to
adjust the mixing amount.
"+" :Operate in same direction as auxiliary channel
"-" :Operate in opposite direction of auxiliary channel
2
(Channel setup)
The channel list screen used for the gain steering channel is displayed. Tap the auxiliary
channel that connected the gain steering channel.
- When all channels are in use, a screen saying "No assignable channel" is displayed, please turn off other mixing
and make an unused channel. You can check the mixing used on the channel setting screen (page 73).
For S-FHSS (analog)
system, channels 5, 6
and 7 are displayed.
If there is no assignable
ch ann el, t ap [ Clo se] .
Turn off other mixing and
make assignable chan-
nels.
6
When fi nished, return to the Mixing menu screen by pressing the HOME button twice.
The mixing rate amount can be adjusted with digital trim DT1 to DT6 or digital dial
DL1, with the
"
Trim / Dial select
"
function (page 64).
Dial / Trim Setting
