Adjustment buttons
- Adjust with the [+] and [-] but-
tons.
- Return to the initial value by
tapping the [reset] buttons.
* Throttle stick position
Brake mixing
Brake 2 "ON"
Brake mixing
Brake 3 "ON"
Brake mixing
Brake 2&3 "ON"
Throttle point
Servo travel
Throttle point
Throttle point
Brake
Normal side
Reverse side
Neutral
91
Function
A.B.S
Throttle point
5~95
Initial value: 30
6
("Throttle point" setup)
Tap the value button of the [Throttle point]. Value input but-
tons appear on the screen. Use the [+] and [-] buttons to ad-
just the operation point.
- Sets the throttle stick position at which the A.B.S. function is performed.
The number is the % display with the full brake position made 100.
Tap [Normal] or [Reverse] to set the operating range.
"Normal" : Neutral to throttle stick point is the range of motion.
"Reverse" : The range from the throttle stick point to the full brake side is the
operating range.
7
When finished, return to the Racing menu screen by pressing the HOME button.
ABS can be independently set for the brakes which are controlled by the Brake 2
and Brake 3 (brake 2 and 3 are auxiliary channels).
"
Brake mixing
"
(page 104) can
be set under the mixing menu.
1/5 scale car and other independent brakes and ABS
Brake 1, 2, 3 can be adjusted independently except the Throttle point of the setting item.
