Function
Use SW1 to SW6 to switch the
"
A.B.S.
"
function ON/OFF.
See the
"
Switch select
"
function (page 67).
Switch setting
The brake return amount, delay amount and cycle speed can be adjusted with digital
trim DT1 to DT6 or digital dial DL1, with the
"
Trim / Dial select
"
function (page 64).
Dial / Trim Setting
Brake return: Approx. 30% (If this value is too high, the braking distance will increase.)
Cycle speed: 5~7
Duty ratio: 0 (When grip is low: - side, when grip is high: + side)
Delay : 10~15%
Throttle point: Approx. 70%
Steering mixing: Off
- When the wheels lock, or the car spins, when the brakes are applied fully
Brake return: Increase from 30%
Duty ratio: Shift from 0 to - side (-1, -2, -3, -4)
Delay : Reduce the delay
- When the braking effect is poor and the braking distance is long when the brakes are
applied fully
Brake return: Decrease from 30%
Duty ratio: Shift from 0 to + side (+1, +2, +3, +4)
DLY: Increase the delay
Example of A.B.S. function setting when S9373SV used
(There will be a slight difference depending on the state of the linkage.)
A.B.S
