Galaxy Hunter Series User Manual

20
4.3.2 Configuring PTZ Function
4.3.2.1 Preset
Preset means a certain position that the camera can make quick orientation to. It includes PTZ
pan and tilt angles, camera focus, and location.
Step 1 Select Setting > PTZ settings > Function > Preset.
The Preset interface is displayed. See Figure 4-8.
Figure 4-8 Preset
Step 2 Set the speed, and click , and to adjust the parameters of direction,
zoom, focus and iris, to move the camera to the position you need.
Step 3 Click Add to add the current position to be a preset, and the preset is displayed in
preset list.
Step 4 Double-click the preset title to edit it.
Step 5 Click to save the preset.
Other Operations
 Click to delete the preset.
 Click Remove All to remove all presets.
4.3.2.2 Tour
Tour means a series of movements that the camera makes along several presets.
