4.6.2 Port
Configure the port numbers and the maximum number of users (includes web, platform client,
and mobile phone client) that can connect to the device simultaneously.
Step 1 Select Setting > Network > Port.
The Port interface is displayed. See Figure 4-69.
Figure 4-69 Port
Step 2 Configure port parameters. For details, see Table 4-23.
0–1024, 1900, 3800, 5000, 5050, 9999, 37776, 37780–37880, 39999, 42323 are
occupied for specific uses.
Do not use the same value of any other port during port configuration.
Table 4-23 Description of port parameters
The max number of users (web client, platform client or mobile phone client)
that can connect to the device simultaneously. The value is 10 by default.
Transmission control protocol port.The value is 37777 by default.
User datagram protocol port. The value is 37778 by default.
Hyper text transfer protocol port. The value is 80 by default.
