82
The multicast IP address of Main Stream/Sub Stream is
224.1.2.4 by default, and the range is
224.0.0.0–239.255.255.255.
The multicast port of corresponding stream: Main Stream: 40000;
Sub Stream1: 40016; Sub Stream2: 40032, and all the range is
1025–65500.
Step 3 Click Save.
Verification
In the Live interface, select RTSP in Multicast, and then you can view the video image with
multicast protocol.
4.6.10 802.1x
Cameras can connect to LAN after passing 802.1x authentication.
Step 1 Select Setting > Network > 802.1x.
The 802.1x interface is displayed. See Figure 4-78.
Figure 4-78 802.1x
Step 2 Select the Enable check box, and then configure parameters. For details, see Table
4-29.
Table 4-29 Description of 802.1x parameters
PEAP (protected EAP protocol).
The user name that was authenticated on the server.
Step 3 Click Save.
4.6.11 QoS
You can solve problems such as network delay and congestion with this function. It helps to
assure bandwidth, reduce transmission delay, packet loss rate, and delay jitter to improve
experience.
0–63 means 64 degrees of priority; 0 for the lowest and 63 the highest.
Step 1 Select Setting > Network > QoS.
