83
The QoS interface is displayed. See Figure 4-79.
Figure 4-79 QoS
Step 2 Configure QoS parameters. For details, see Table 4-30.
Table 4-30 Description of QoS parameters
Configure the priority of the data packets that used for network
surveillance. 0 for the lowest and 63 the highest.
Configure the priority of the data packets that used for configure or
checking.
Step 3 Click Save.
4.6.12 Access Platform
4.6.12.1 P2P
P2P is a private network traversal technology which enables user to manage devices easily
without requiring DDNS, port mapping or transit server.
Scan the QR code with your smart phone, and then you can add and manage more devices on
the mobile phone client.
Step 1 Select Setting > Network >Access Platform > P2P.
The P2P interface is displayed. See Figure 4-80.
Figure 4-80 P2P
When P2P is enabled, remote management on device is supported.
