106
Select IP address, IP segment, MAC address or all IP addresses.
IP address: Select IP version and enter the IP address of the
host to be added.
IP segment: Select IP version and enter the start address
and end address of the segment to be added.
MAC address: Enter MAC address of the host to be added.
All IP addresses: Set all IP addresses in trusted list or
restricted list.
Set access ports. You can select all ports or the ports in defined
areas.
Device all ports: Set all IP port in trust list or Banned list.
When selecting BannedList in Mode, and All IP Address in
Rule Type, you cannot select the Device All Ports check
box.
Device start server port and Device end server port: Set
Device start server port and device end server port, and the
range is 1–65535.
Step 4 Click OK, and the Firewall interface is displayed.
Step 5 Click Save.
4.8.6 Peripheral
4.8.6.1 Serial Port Settings
Set the serial port of the external device.
Step 1 Select Setting > System > Peripheral > Serial Port Settings.
The Serial Port Settings interface is displayed. See Figure 4-111.
Figure 4-111 Serial port settings
Step 2 Configure serial port settings parameters. For details, see Table 4-41.
Table 4-41 Description of serial port settings parameters
