Galaxy Hunter Series User Manual

10
Figure 4-3 Live
Table 4-1 Description of function bar
No.
Function
Description
1
Encode bar
Sets stream type and protocol.
2
Live view
Displays the real-time monitoring image.
3
Live view function bar
Functions and operations in live viewing.
4
Window adjustment bar
Adjustment operations in live viewing.
4.2.2 Encode bar
For encode bar, see Figure 4-4.
Figure 4-4 Encode bar
 Main Stream: It has large bit stream value and image with high resolution, but also
requires large bandwidth. This option can be used for storage and monitoring. For details,
see "4.5.2.1 Video."
 Sub Stream: It has small bit stream value and smooth image, and requires less bandwidth.
This option is normally used to replace main stream when bandwidth is not enough. For
details, see "4.5.2.1 Video."
 Protocol: You can select the network transmission protocol as needed, and the options
are TCP, UDP and Multicast.
Before selecting Multicast, make sure that you have set the Multicast parameters.
4.2.3 Live View Function Bar
For the live view function bar, see Table 4-2.
Table 4-2 Description of live view function bar
