79
Figure 4-75 SNMP (2)
Step 2 Select SNMP version to enable SNMP.
Select V1, and the system can only process information of V1 version.
Select V2, and the system can only process information of V2 version.
Select V3, and then V1 and V2 become unavailable. You can configure user name,
password and authentication type. It requires corresponding user name, password
and authentication type to visit your device from the server.
Using V1 and V2 might cause data leakage, and V3 is recommended.
In Trap Address, enter the IP address of the PC that has MIB Builder and MG-SOFT
MIB Browser installed, and leave other parameters to the default.
Table 4-27 Description of SNMP parameters
The listening port of the software agent in the device.
Read Community,
Write Community
The read and write community string that the software agent
supports.
You can enter number, letter, underline and dash to form the name.
The target address of the Trap information sent by the software agent
in the device.
The target port of the Trap information sent by the software agent in
the device.
