USER MANUAL FOR SR-1000 STANDALONE INTEGRATED MEDIA BLOCK™
7. CONFIGURATION
1
Audio output based on SMPTE audio channel configuration labels can be configured in this tab,
2
Audio output for individual SMPTE audio channel labels can be changed here.
3
Check the Use SMPTE audio labels checkbox to route audio output based on SMPTE audio
channel configuration labels.
2
3
Figure 54: Using DCP Channel labels
