USER MANUAL FOR SR-1000 STANDALONE INTEGRATED MEDIA BLOCK™
8. AUDIO PROCESSING
Bass/Treble
When it is necessary to increase or decrease the low frequencies or high frequencies as a
whole, the Bass/Treble option can be used for the overall adjustment. All channels except LFE
can be adjusted individually.
It is recommended to adjust the Bass/Treble before adjusting the gain of each band
one-by-one.
Figure 70: Bass/Treble
1
[Bass (dB)]
The adjustment range for Bass is from -6dB to +6dB.
2
[Treble (dB)]
The adjustment range for Treble is from -12dB to +12dB.
3
[Treble Corner Frequency]
The Treble Corner Frequency can be set to 1kHz, 2KHz, 3kHz
or 4kHz.
1
3
2
