USER MANUAL FOR SR-1000 STANDALONE INTEGRATED MEDIA BLOCK™
7. CONFIGURATION
Audio Channel Mapping
Using Audio Channel Mapping, audio output from the SR-1000 can be re-mapped to appear
on different audio channels.
1
Audio output based on the number of audio channels in the audio track of the DCP can be
configured in this tab.
2
The preset for the number of audio channels in the audio track can be changed here.
3
Use the Preset button to configure audio presets.
Refer to Section 7.2.1.1 for details
Figure 53: Using DCP Channel order
1
2
3
