3 SETUP AND USE SETPOINTS MODE
3
29 Range: 0 to 200°C or OFF, in steps of 1°C (32 to 392°F
in steps of 1°F if Fahrenheit)
Factory Value = OFF
or
Range: 0 to 200°C or OFF, in steps of 1°C
(32 to 392°F in steps of 1°F if Fahrenheit)
Factory Value = OFF; Manual Reference: 3.18
210
Range: 0 to 200°C or OFF, in steps of 1°C
(32 to 392°F in steps of 1°F if Fahrenheit)
Factory Value = OFF; Manual Reference: 3.18
or
Range: 0 to 200°C or OFF, in steps of 1°C
(32 to 392°F in steps of 1°F if Fahrenheit)
Factory Value = OFF; Manual Reference: 3.18
211
Range: 0 to 200°C or OFF, in steps of 1°C
(32 to 392°F in steps of 1°F if Fahrenheit)
Factory Value = OFF; Manual Reference: 3.18
or
Range: 0 to 200°C or OFF, in steps of 1°C
(32 to 392°F in steps of 1°F if Fahrenheit)
Factory Value = OFF; Manual Reference: 3.18
212
Range: 0 to 200°C or OFF, in steps of 1°C
(32 to 392°F in steps of 1°F if Fahrenheit)
Factory Value = OFF; Manual Reference: 3.18
or
Range: 0 to 200°C or OFF, in steps of 1°C
(32 to 392°F in steps of 1°F if Fahrenheit)
Factory Value = OFF; Manual Reference: 3.18
213
Range: 0 to 200°C or OFF, in steps of 1°C
(32 to 392°F in steps of 1°F if Fahrenheit)
Factory Value = OFF; Manual Reference: 3.18
or
Range: 0 to 200°C or OFF, in steps of 1°C
(32 to 392°F in steps of 1°F if Fahrenheit)
Factory Value = OFF; Manual Reference: 3.18
214
Range: 0 to 200°C or OFF, in steps of 1°C
(32 to 392°F in steps of 1°F if Fahrenheit)
Factory Value = OFF; Manual Reference: 3.18
or
Range: 0 to 200°C or OFF, in steps of 1°C
(32 to 392°F in steps of 1°F if Fahrenheit)
Factory Value = OFF; Manual Reference: 3.18
TABLE 3–3: 269PLUS SETPOINTS (SHEET 4 OF 25)
PAGE LINE INFORMATION LINE
STATOR #2 ALARM LEVEL
= XXX DEGREES C
RTD #2 ALARM LEVEL
= XXX DEGREES C
STATOR #2 HIGH ALARM
LEVEL = XXX DEGREES C
RTD #2 HIGH ALARM
LEVEL = XXX DEGREES C
STATOR #2 TRIP LEVEL
= XXX DEGREES C
RTD #2 TRIP LEVEL
= XXX DEGREES C
STATOR #3 ALARM LEVEL
= XXX DEGREES C
RTD #3 ALARM LEVEL
= XXX DEGREES C
STATOR #3 HIGH ALARM
LEVEL = XXX DEGREES C
RTD #3 HIGH ALARM
LEVEL = XXX DEGREES C
STATOR #3 TRIP LEVEL
= XXX DEGREES C
RTD #3 TRIP LEVEL
= XXX DEGREES C
