ActionStep
In the Process Picture:3
•
Click the Mixer valve and select By-pass.
Result: The Mixer valve switches to By-pass position.
If the loop is connected to:4
•
the Injection valve, continue to step 6.
•
the Loop valve, continue to step 5.
In the Process Picture:5
•
Click the Loop valve.
•
Select the position the loop is connected to, for example Position 1.
Result: The Loop valve switches to the selected position.
In the Process Picture:6
•
Click on the buffer inlet valve A.
•
Select the inlet position to be used for sample injection, for example A2.
Result: Inlet valve A switches to the selected port.
188 ÄKTA pure User Manual 29119969 AB
5 Operation
5.7 Sample application
5.7.2 Sample application using a Superloop
™
