Illustration of the pump piston rinsing system
1
2
3
4
5
DescriptionPart
Rinsing system tube holder, top1
Rinsing system tube2
Rinsing system tube holder, bottom3
Outlet tubing4
Inlet tubing5
System pump rinsing systems flow path
The illustration below shows the tubing configuration of the pump piston rinsing system of the system
pumps.
