D20/D200 Software Configuration, continued
Procedure:
Code Download
D20 Base
To download a flash code file to a D20 Base type of D20ME module.
Step Action
Code Download for D20 Base type D20ME
1
Restart the D20ME.
2
As soon as messages display on the monitor, press the Esc key within 5
seconds.
Result:
You are prompted with the message: “Are you sure you wish to
generate a default configuration? (y/n)”
.
3
Type y (or Y).
Results:
The current configuration file is overwritten with the default
configuration. The 68K Monitor is initiated.
4
Press
ENTER.
Result:
The 68K Monitor login dialog screen appears
5
To login: for Login: type westronic and press
ENTER, then for
Password: type rd and press
ENTER.
Results:
A Welcome message appears, followed by the D20M> prompt.
6
Type sp to suspend all processes running on the D20ME
7
Type erase to clear the flash. This will take several seconds.
Result:
Flash Erased will be displayed when completed
Optional Step 1: Speed-up communications to shorten download time.
8
Type Baud 38400 and press
ENTER.
Note:
Speeds up to 230.4 kbps, or lower speeds may be chosen based
on ambient EMI, WESMAINT cable length, PC and
communication software limitations, etc. Refer to “Appendix
D: Changing the Baud Rate”, page 127 for supported speeds.
Result:
The monitor will now be communicating at 38.4 kbps
9
Configure the terminal emulator software to communicate at the same
speed, and reconnect to the 68K monitor.
