Appendix A: Product Combinations
Introduction
Use Table 1 to check the combinations for the D20 M++, D20ME, D20EME,
GreenSpring Ethernet, and MicroMemory cards in the three available main chassis
types:
• Check that a main processor board is compatible with a chassis type
• Check that a main processor board and Ethernet and/or memory card
combination is compatible with a chassis type
• Check that a main processor board and New or Old D.20 peripherals are
compatible with a chassis type
Use Table 2 to check the Base compatibility and Minimum BootROM for D.20
Peripherals boards.
Compatibility:
Table 1
Use the following tables to check the compatibility of the components you want to
combine. Notes that follow the table give restrictions that apply to these
combinations.
Note: D20M++ showing in the Board Combination column refers to the now
obsolete main processor board. It is included for customers who already
have this board installed in their D20/D200 system.
Chassis Type
Board Combinations
(All in the same chassis)
D20 Non-VME
(1 Slot Horizontal)
D20ME
(5 Slot Horizontal)
D200 VME
(9 Slot Vertical)
D20ME Yes (Note 1) Yes (Note 2,6) Yes
D20ME, EME N/A Yes (Note 2,3,6) Yes
D20ME, GreenSpring N/A Yes (Note 2,3,6) Yes
D20ME, MicroMemory N/A Yes (Note 2,4,6) Yes (Note 4)
D20ME, GreenSpring, MicroMemory N/A Yes (Note 2,3,4,6) Yes (Note 4)
D20M++ Yes Yes (Note 6) Yes
D20M++, EME N/A Yes (Note 3,5,6) Yes (Note 5)
D20M++, GreenSpring N/A Yes (Note 3,6) Yes (Note 3)
D20M++, MicroMemory N/A Yes (Note 6) Yes
D20M++, GreenSpring, MicroMemory N/A Yes (Note 3,6) Yes
D20ME, D20M++, EME N/A Yes (Note 2,3,5,6) Yes (Note 5)
D20ME, D20M++, MicroMemory N/A N/A Yes (Note 4,5)
D20ME, D20M++, GreenSpring, MicroMemory N/A N/A Yes (Note 4,5)
D20ME, New D.20 Peripherals Yes Yes Yes
D20ME, Old D.20 Peripherals Yes (Table 2) Yes (Table 2) Yes (Table 2)
