GE D20 - I;O Peripheral Board Configuration

D20/D200
Installation and Operations Guide
GE Energy
994-0078-2.00-7 General
62
Full
Connections and Configuration, continued
I/O Peripheral
Boards:
Jumper
Settings
Jumper location and configuration settings are given below. You can also refer to the
Module Layouts for these boards:
• D20A Analog Input
− WESDAC D20A see 511-0101-ML
− WESTERM D20A see 517-0163-ML
• D20S Digital Input
− WESDAC D20S see 507-0101-ML
− WESTERM D20S see 517-0165-ML
• D20K Control Output
− WESDAC D20K see 508-0101-ML
− WESTERM D20K see 517-0164-ML
• D20C Combination I/O
− WESDAC D20C see 504-0002-ML
− WESTERM D20C see 517-0169-ML
• D20AC (Alternating Current) Analog Input
− WESDAC D20AC see 511-0104-ML for 40 – 150V power and 511-0106-ML
for 20 – 60V power
