Connections and Configuration, continued
D20ME II Jumpering, continued
Table: VME
Jumper
Options
The following tables su
mmarize the jumper settings for each board function and
position that is installed in a CCU for D20 or D200:
Single Node
For D20 or D200:
Board Function JP1
Master /
Slave
JP2
VME Address Bits
4 3 2 1
JP3-1
RTC -
SERCLOCK
JP3-2
RTC -
BRTC
Single Node OUT IN IN IN IN OUT IN
Multi-Node
For D20 or D200:
Board Function JP1
Master /
Slave
JP2
VME Address Bits
4 3 2 1
JP3-1
RTC -
SERCLOCK
JP3-2
RTC -
BRTC
Node #1 OUT IN IN IN OUT IN IN
Node #2 IN IN IN OUT IN IN OUT
Node #3 IN IN IN OUT OUT IN OUT
Node #4 IN IN OUT IN IN IN OUT
Node #5 IN IN OUT IN OUT IN OUT
Node #6 IN IN OUT OUT IN IN OUT
Node #7 IN IN OUT OUT OUT IN OUT
Node #8 IN OUT IN IN IN IN OUT
Notes:
• Single Node is the factory default configuration.
• If you have a single-node implementation with Ethernet or Memory expansion or
both, configure jumpers as Single Node.
