D20/D200
Installation and Operations Guide
GE Energy
994-0078-2.00-7 General
64
Full
Connections and Configuration, continued
WESDAC
Jumper
Settings
The following table shows jumper settings for the different Base software.
Option Jumper
Number
Jumper
Position
Jumper
Setting
1A 1B
Jumper Definition – S/W Compatibility
Z1 – Z4 1 – 2 ALL OUT
√
Z5 1 – 2 IN
√
ALL OTHER BASES
Z1 – Z4 1 – 2 ALL IN
√
Z5 1 – 2 IN
√
BASE 3.11 OR OLDER
(D20M, D20M+ & D20M++)
Note
If you have the D20ME main board, then set the jumper definition to: ALL OTHER
BASES.
