GE D20 - WESTERM D20 K: Settings

D20/D200
Installation and Operations Guide
GE Energy
994-0078-2.00-7 General
70
Full
Connections and Configuration, continued
WESTERM
D20K: Settings
The following table gives jumper settings for Z2 to Z39.
Option Jumper
Number
Jumper
Position
Jumper
Setting
1A 1B 1C
Jumper Definition
1 – 2 IN
√
Control O/P Source = D20 Peripheral DC Supply Voltage Z2 & Z3
2 – 3 IN
√
Control O/P Source = External Source Supplied to TB1 – 1 & 54
Option
2A 2B 2C
1 – 2 IN
√
T/C Configuration for Control O/P 1 – 8 = (T/C 1 – 8) Z8
2 – 3 IN
√
R/L Configuration for Control O/P 1 – 8 = (R/L 13 – 16)
1 – 2 IN
√
T/C Configuration for Control O/P 9 – 16 = (T/C 9 – 16) Z9
2 – 3 IN
√
R/L Configuration for Control O/P 9 – 16 = (R/L 9 – 12)
1 – 2 IN
√
T/C Configuration for Control O/P 17 – 24 = (T/C 17 – 24) Z14
2 – 3 IN
√
R/L Configuration for Control O/P 17 – 24 = (R/L 5 – 8)
1 – 2 IN
√
T/C Configuration for Control O/P 25 – 32= (T/C 25 – 32) Z15
2 – 3 IN
√
R/L Configuration for Control O/P 25 – 32 = (R/L 1 – 4)
Option Jumper
Number
Jumper
Position
Jumper
Setting
3A 3B 3C 3D
Jumper Definition
1 – 2 & 3 – 4 IN
√
T/C Configuration (T/C 1 – 8)
1 – 2 IN
√
R/L Configuration (R/L 13 – 16)
Z5 – Z7
Z19 – Z21
Z30 & Z31
2 – 3 IN
√
Form C or Open Collector Control Outputs 1 – 8
1 – 2 & 3 – 4 IN
√
T/C Configuration (T/C 9 – 16)
1 – 2 IN
√
R/L Configuration (R/L 9 – 12)
Z4, Z10,
Z11, Z18,
Z22, Z29,
Z32, Z33
2 – 3 IN
√
Form C or Open Collector Control Outputs 9 – 16
1 – 2 & 3 – 4 IN
√
T/C Configuration (T/C 17 – 24)
1 – 2 IN
√
R/L Configuration (R/L 5 – 8)
Z12, Z13,
Z23, Z24,
Z25, Z34,
Z35, Z36
2 – 3 IN
√
Form C or Open Collector Control Outputs 17 – 24
1 – 2 & 3 – 4 IN
√
T/C Configuration (T/C 25 – 32)
1 – 2 IN
√
R/L Configuration (R/L 1 – 4)
Z16, Z17,
Z26, Z27,
Z28, Z37,
Z38, Z39
2 – 3 IN
√
Form C or Open Collector Control Outputs 25 – 32
