D20/D200 Software Configuration, continued
Procedure (continued)
Step Action
Optional Step 1: Speed-up communications to shorten download time.
8
Type Baud 38400 and press
ENTER .
Note:
Speeds up to 230.4 kbps, or lower speeds may be chosen based
on ambient EMI, WESMAINT cable length, PC and
communication software limitations, etc. Refer to “Appendix
B: 68K Monitor Commands”, page 127 for supported speeds.
Result:
The monitor will now be communicating at 38.4 kbps
9
Configure the terminal emulator software to communicate at the same
speed, and reconnect to the 68K monitor.
Optional Step 2: Provide feedback during download
10
If the communication software you are using does not have any
“progress indicator”, echo can be enabled to visually display the code
file on your monitor as it is transferred.
This option can be usually found in the communication settings or
properties of the communication program.
Note:
Enabling echo may slow transfer slightly.
Download Code File
11
Press
ENTER to verify that communication is active.
Result:
The D20MES> prompt will return if connection is active
12
Type dl and press
ENTER to put the D20ME into the state where it is
ready to receive the downloadable code file
13
Click Transfer | Send Text File from menu bar
Result:
A dialog box will open, prompting you to locate the Down.shx
file that you wish to download.
14
Select the correct file, and click Open to start the transfer
Caution:
Do not hit any keys on keyboard during download.
Result:
The file transfer may take from less than 10 to over 30
minutes, depending on communication speed selected.
When complete, the D20MES> prompt will return.
