Peripheral Compatibility: Table 2 (continued)
Product Vintage Release
Date
D.20 Communications
Design Detail
Base
Compatibility
Minimum
BootROM
Vintage 01A-10A Shunt Cap / Perpal 1 V1.5 All Any BootROM
Vintage 11A, 13A-17A 96/09/11 Series Cap / Perfuni V0.0 D20 base 3.51
and newer
P002 3.05
P002-2 3.05 or
P002-3 1.00
Vintage 12A (Note 1) 96/08/08 Series Cap / Perpal 1 V1.5 All Any BootROM
WESDAC
D20S
(507-0101)
Vintage 18A-current 98/06/11 Jumper Caps (Shunt/Series)
/ Perfask V0.0 See note 3
All Any BootROM
Vintage 01A-19A Shunt Cap / Perpal 3 V1.2
Cannot use 2nd D.20 com
port (for redundant link)
All Any BootROM
Vintage 20A-23A 96/11/19 Series Cap / Perfuni V0.0
Cannot use 2nd D.20 com
port (for redundant link)
D20 base 3.51
and newer
P002 3.05
P002-2 3.05 or
P002-3 1.00
Vintage 24A-current 98/06/25 Jumper Caps (Shunt/Series)
/ Perfc V0.0 See note 3
All Any BootROM
WESDAC
D20C (504-
0002)
Vintage 01A-19A Shunt Cap / Perpal 3 V1.2
Cannot use 2nd D.20 com
port (for redundant link)
All Any BootROM
Vintage 01A-04A Shunt cap All D20 Base
All D20M++ Base
Any BootROM
Vintage 05A-07A 96/01/03 Series cap D20 base 3.51
and newer
P002 3.05
P002-2 3.05 or
P002-3 1.00
Vintage 08A (Note 1) 97/05/07 Shunt cap All D20 Base
All D20M++ Base
Any BootROM
Vintage 09A-current 98/08/07 Jumper caps (Shunt/Series)
See note 2
All Any BootROM
WESTERM
M+
(517-0224)
Vintage 01A-04A Shunt cap All D20 Base
All D20M++ Base
Any BootROM
Vintage 01A-04A Shunt cap All D20 Base
All D20M++ Base
Any BootROM
Vintage 05A-06A 96/01/03 Series cap D20 base 3.51
and newer
P002 3.05
P002-2 3.05 or
P002-3 1.00
Vintage 07A-current 98/08/07 Jumper caps (Shunt/Series)
See note 2
All Any BootROM
WESTERM
M+
(517-0225)
Vintage 01A-04A Shunt cap All D20 Base
All D20M++ Base
Any BootROM
