User Manual Druck DPI620 Genii
7 Foundation™ Fieldbus
Introduction 7.1
FOUNDATION™ Fieldbus (FF) is a device application for
configuration of FF enabled field devices. On-line connection
is via the integrated H1 modem. Devices directly connected
to an H1 field segment can be configured and supported by
FF.
Start up 7.2
FOUNDATION™ Fieldbus is started by selecting:
DASHBOARD >> FIELDBUS
Task can be selected for CH1, CH2, P1 and P2. Refer to
Section 2.1.
FOUNDATION™ Fieldbus can also be selected from the
CALIBRATOR function.
Select: COMMUNICATOR channel from TASK SETTINGS
FUNCTION >> FIELDBUS
Note: When Fieldbus is operational, only Volts measure is
a valid mode for channel 2.
06 June 2013 K0541 issue 1 Page 109 of 175
