GE Druck DPI 620 Genii - 11 Display Icons

User Manual Druck DPI620 Genii
11 Display Icons
Table 11-1 Dashboard Icons
Advanced
Hart ®
Calibrator
Help
Data Logging
LED (shows status)
Blue – Active
Red – Alarm
Green - Connected
Touchscreen
Multimeter
Documenting
Scope
Foundation
Fieldbus
Settings
Files
Status
Applications
Devices
06 June 2013 K0541 issue 1 Page 175 of 175
