Table 8-14 TC mV (measure or source) error limits
Input
or
output
Calibrator uncertainty
TC (mV)
Permitted
DPI 620 error (mV)
TC (mV)
(measure)
(source)
(measure)
(source)
-10
0.0036
0.00011
0.0085
0.0090
0
0.0036
0.0001
0.008
0.008
10
0.0036
0.00011
0.0085
0.0090
25
0.0036
0.00015
0.0091
0.0100
50
0.0037
0.00025
0.010
0.0125
100
0.004
0.00046
0.0125
0.0170
Procedures (CH1): Cold Junction (TC method) and CJ 8.12
(measure)
Note: Do the TC mV (measure) calibration before the cold
junction calibration. The conditions for CJ calibration are as
follows:
• Battery mode (with DC charger disconnected)
• CH1 active
• CH2 set to “None”
• Burnout Detection off
• Use miniature TC connectors
There are two methods of doing a cold junction test; the CJ
(TC Method) is the preferred method. Both procedures are
described as follows:
06 June 2013 K0541 issue 1 Page 162 of 175
