GE Infinity M Series - Table 1 Rectifiers and Converters

NE-M Installation Guide H5692448
850050111 Issue 03 August 2017 13
Table 1 Rectifiers and Converters
Rectifier/Converter Input Output Eco Compatible
Eco Rectifier
blue
NE050ECO48ATEZ
ac 110/200-240 Vac
dc 60Vdc (+/-30V)
to 310Vdc (+/-150)
11A max
48V, 50A
10
Yes
6
Eco Rectifier
orange
NE100ECO24TEZ
ac 110/200-240 Vac
dc 60Vdc (+/-30V)
to 310Vdc (+/-150)
11A max
24V, 100A
7
Yes
6
Converter
blue
NE040DC48ATEZ
24 Vdc
48V, 40A
Yes
NE030DC48A
48V, 30A
Yes
Converter
orange
NE075DC24A 48 Vdc 24V, 75A
Yes
Rectifier
blue
NE075AC48ATEZ 110/200-277 Vac 48V, 75A
8
AC Only
9
NE055AC48ATEZ 110/200-277 Vac 48V, 55A
10
NE050AC48ATEZ 110/200-277 Vac 48V, 50A
10
NE050AC48A
12
200-240 Vac 48V, 50A
12
Rectifier
orange
NE100AC24ATEZ 110/200-277 Vac
24V, 100A
11
AC Only
9
NE100AC24A
12
208/200-240 Vac
NE850 Slot Filler
6
REQUIRED – Eco rectifiers in all DC (PV or solar) powered rectifier positions.
RECOMMENDED – Eco rectifiers in all Eco system rectifier positions.
NOT RECOMMENDED – non-Eco rectifiers in Eco systems.
Non Eco rectifiers will not function properly when powered by DC (PV or solar) input in Eco systems.
Use of non-Eco rectifiers in Eco systems increases the risk of improperly filling all system rectifier positions.
Non Eco rectifiers may be installed in AC powered rectifier positions of Eco systems.
7
44A with 120Vac input
8
22A with 120Vac input
9
NOT RECOMMENDED for use in Eco systems - Non Eco rectifiers will not function properly when powered by DC (PV or
solar) input in Eco systems.
Use of non-Eco rectifiers in Eco systems increases the risk of improperly filling system rectifier positions.
10
25A with 120Vac input
11
50A with 120Vac input
12
Non-TEZ rectifiers are no longer orderable and have lower efficiency than TEZ rectifiers
