GE Infinity M Series - Table 14 Alarm and Control Inputs - Descriptions, BLS Pins, and Signal Names

NE-M Installation Guide H5692448
850050111 Issue 03 August 2017 83
Table 13 Alarm - Descriptions, BLS Pins, and Signal Names
Description
BSL Pin Number
Signal Name
55
UR2O
User Relay 2
56
UR2C
57
UR2R
58 VLVR
Very Low Voltage
59
VLVC
60
VLVO
Table 14 Alarm and Control Inputs - Descriptions, BLS Pins, and Signal Names
Description BSL Pin Number Signal Name
Low Voltage 2 Disconnect State Detect 61 LVD2
Fuse Alarm Major 63 FAJ
Fuse Alarm Minor 65 FAN
Auxiliary Alarm Major 64 AMJ
Auxiliary Alarm Minor 66 AMN
Timer Float Control 67 TFLT
Timer Boost Control 68 TBST
Plant Battery Test 71 PBT
Open String Detect 72 OS
Transfer Rectifier 1 73 TR1
General Purpose Input 4
Previously TEQ
74
IN-4
Previously TEQ
General Purpose Input -5
Previously Engine Transfer
75
IN-5
Previously ETR
General Purpose Input -5 RTN
Previously Engine Transfer Return
76
IN-5R
Previously ETRR
Reserve Operation 77 RO
Reserve Operation RTN 78 ROR
Transfer Rectifier 2 79 TR2
Transfer Rectifier 4 80 TR4
Reserve Battery-Emergency Power Off 81 RBRPO
General Purpose Input 1 82 IN-1
BTP or General Purpose Input 2 83 IN-2/BTP
Low Voltage 1 Disconnect State Detect 84 LVD1
Transfer Rectifier 3 85 TR3
General Purpose 4-20mA Measuring Circuit 87 4-20mA
General Purpose 4-20mA Measuring Circuit-RTN 88 4-20mAR
BTPFLT or Generic Input 3 89 IN-3/ BTPFLT
Low Voltage 3 Disconnect State Detect
Also
Battery Thermal Protect Major
90 LVD3/ BTMJ
External Voltage Input 91 EXT-V
External Voltage Input -RTN 92 EXT-VR
