NE-M Installation Guide H5692448
850050111 Issue 03 August 2017 52
Step Action – Pulsar Plus
3
Auxiliary Input Connector
Connect and wire auxiliary inputs as required to Connector J3. J3 is an auxiliary input connector.
Utilize cable as necessary to obtain the desired connections to the inputs shown below.
Input Alarm Cable comcodes for J3 are: 50 ft.: CC848817651, 150 ft.: CC848817668.
Table 5 Auxiliary Input Connector Signals - Pulsar Plus
Pin Wire Signal Name
18
Description
18
1 BK
Aux Input 1
(Aux1)
Auxiliary input to monitor a contact closure or open to its respective
return on pin 8, Auxiliary Input Return.
2 BR
Aux Input 2
(Aux2)
Auxiliary input to monitor a contact closure or open to its respective
return on pin 8, Auxiliary Input Return.
3 R
Aux Power
Major Input
(AMJ)
Auxiliary input to monitor a contact closure to the non-grounded
side of a dc bus (±24V/-48V) to create the standard Auxiliary Power
Major alarm.
Generator Running in Eco applications.
4 O
Plant Battery
Test/ Group
Standby/TR
(GSTR)
Dedicated input to be monitored for a contact closure to its
respective return on pin 9, Plant Battery Return. This signal is used
for the Plant Battery Test and Group Standby Feature.
5 Y
Emergency
Power Off
(EPO)
Dedicated EPO input to be monitored for a contact closure to its
respective return on pin 10, Emergency Power Off Return.
6 G
Aux Input 3
(Aux3)
Auxiliary input to monitor a contact closure or open to its respective
return on pin 8.
7 BL
Aux Input 4
(Aux4)
Auxiliary input to monitor a contact closure or open to its respective
return on pin 8.
8 V
Aux Input
Return
(Aux_R)
Return for Auxiliary Inputs 1-4.
9 S
Plant Battery
Test/Group
Standby/TR
Ret.(GSTR_R)
Return for Plant Battery Test and Group Standby.
10 W
Emergency
Power Off Ret.
(EPO_R)
Return for EPO input.
18
Inputs are reconfigured for specific use for specific Eco applications.
