NE-M Installation Guide H5692448
850050111 Issue 03 August 2017 51
Step Action – Pulsar Plus
1
Analog Interface Connector
Connect and wire to shunt and alarms.
J1 is a 6-pin connector provided for analog interface to a plant shunt, distribution alarms, and open battery
string alarms. Typically, a factory installed plant wire harness plugs into this connector. This wire set has a
purple wire with a Faston ® receptacle for connecting the Open String Alarm from field installed battery
disconnect breakers.
Table 4 Analog Interface Connector Signals – Pulsar Plus
Pin Signal
1 Shunt+
2 Shunt Reference
5 Open String
6 Fuse Alarm Major -48V
2
1-Wire Peripheral Connector
Connect and wire to VT-Probe, external ambient probe, or Remote Voltage Monitor.
J2 is an RJ-45 receptacle for connecting to 1-Wire devices.
