Millennium II Alarm & Control Signals
In a standard Galaxy Power System (GPS) configuration, plant level alarms are sent to the controller via the Bay Interface
Card (BIC) through serial data communication. The following alarm inputs are provided for discretionary use in other
applications.
Table 12 Alarm and Control - Signal Names and BSL Pins
Pin
Number
Signal Name
Pin
Number
Signal Name
Pin
Number
Signal Name
1
PCRAO
33
MJFR
65
FAN
2 PCRAC 34 MNFR 66 AMN
3 PCRAR 35 MNFC 67 TFLT
4 PCRVR 36 MNFO 68 TBST
5 PCRVC 37 BDO 69 TRTN
6 PCRVO 38 BDC 70 PBTR
7
PCREO
39
BDR
71
PBT
8 PCREC 40 ACFR 72 OS
9 PCRER 41 ACFC 73 TR1
10 PMJAR 42 ACFO 74 TEQ
11 PMJAC 43 RFAO 75 IN-5
12 PMJAO 44 RFAC 76 IN5-R
13
PMJEO
45
RFAR
77
RO
14 PMJEC 46 HVR 78 ROR
15 PMJER 47 HVC 79 TR2
16 PMJVR 48 HVO 80 TR4
17 PMJVC 49 UR1O 81 RBRPO
18 PMJVO 50 UR1C 82 IN-1
19 PMNAO 51 UR1R 83 IN-2 / BTP
20 PMNAC 52 CTLRR 84 LVD1
21 PMNAR 53 CTLRC 85 TR3
22 PMNVR 54 CTLRO 86 -
23 PMNVC 55 UR2O 87 4-20mA
24 PMNVO 56 UR2C 88 4-20mA-R
25 5V 57 UR2R 89 IN-3/ BTPFLT
26 - 58
UR3R
Now VLVR
90 LVD3/ BTMJ
27 - 59
UR3C
Now VLVC
91 EXT-V
28 PMNER 60
UR3O
Now VLVO
92 EXT-VR
29 PMNEC 61 LVD2 93 ABS
30 PMNEO 62 LVD2R 94 ABS
31 MJFO 63 FAJ 95 DG
32 MJFC 64 AMJ 96 DG
