DIRECTION 5750007-1EN, REV. 1 LOGIQ E10 BASIC SERVICE MANUAL
Chapter 8 Replacement Procedures 8 - 35
3.
If the Side Covers are replaced, the Air Filter
must be transferred to the replacement.
Remove the Air Filter and transfer it to the
replacement.
Release the tab by pressing inward on the
outer edge of the Filter (either side) and
gently slide the Filter out of the LOGIQ E10.
Always clean the Filter when it is removed.
Inspect the Filter. Always replace the Filter,
if it is damaged or you suspect damage.
4.
Re-install or replace Filter.
5.
When replacing Side Covers for a LOGIQ E10 used in veterinary environment, the LOGIQ E10 Spare Parts
Handling for Veterinary Systems MUST BE re-installed before the LOGIQ E10 returned for use.
See: "Label Placement for the LOGIQ E10 used in a Veterinary Environment" on page 8-58.
Table 8-23 Side Cover(s)/Side Air Intake (Filter) inspection / removal
Steps Corresponding Graphic
To Next Page
