DIRECTION 5750007-1EN, REV. 1 LOGIQ E10 BASIC SERVICE MANUAL
Chapter 8 Replacement Procedures 8 - 45
8-6-7 Rear Cover/Air Exhaust replacement
NOTE: When replacing the Rear Cover Assembly for a LOGIQ E10 used in a veterinary environment,
the LOGIQ E10 Spare Parts Handling for Veterinary Systems MUST BE re-installed before the
LOGIQ E10 is returned for use. See: "Label Placement for the LOGIQ E10 used in a Veterinary
Environment" on page 8-58.
Table 8-40 Manpower / Time and Tools
Manpower /
Time
Tools / PPE
One person /
15 minutes
Refer to: 8-2-5 "Tools needed for servicing the LOGIQ E10" on page 8-6 /
8-2-6 "PPE Required During Service" on page 8-6.
Table 8-41 Preparations and Preparation Links
Preparations - you must perform the following steps
1. Power down the system.
2. Disconnect the mains power cable from the wall outlet and External I/O Cabling.
3. Remove the Side Covers and Mains Cable Hook.
Preparation Links (if you need more information):
• 4-2-4 "Power SHUT DOWN" on page 4-9.
• 8-6-3 "Side Cover(s)/Side Air Intake (Filter) inspection / replacement" on page 8-33.
• 8-6-6 "Mains Cable Hook replacement" on page 8-43.
