DIRECTION 5750007-1EN, REV. 1 LOGIQ E10 BASIC SERVICE MANUAL
8 - 54 Section 8-6 - Replacing Covers and Bumpers
Rear Trim Cover installation
Calibration and adjustments
No calibrations or adjustments are needed after this part replacement.
Verification
Perform the following steps to verify that the product is functioning as intended after this replacement:
1.) Connect cables removed earlier
2.) Power up the system to verify that it operates as intended.
Functional Checks
Perform the following functional checks to confirm the system is operational before returning the system
to the customer.
Table 8-53 Rear Trim Cover installation
Steps
Corresponding Graphic
1. Position trim cover into place, with the upper edge under the Top Cover and with both hands,
firmly press in, evenly to install.
2. Re-install all Covers removed and Mains Cable Hook.
Table 8-54 Rear Trim Cover replacement Functional Checks
See:
Section Functional Check Debrief Script
4-2-3 Power ON/Boot Up
LOGIQ E10 Basic Service Manual, Direction
5750007-1EN, Rev. 1. Equipment passed all
required checks and is ready for use.
4-2-7 B-Mode Checks
4-2-4 Power SHUT DOWN
