GE LOGIQ E10 Service Manual

DIRECTION 5750007-1EN, REV. 1 LOGIQ E10 BASIC SERVICE MANUAL
8 - 78 Section 8-6 - Replacing Covers and Bumpers
Covers under XY / Frogleg motors installation
Calibration and adjustments
No calibrations or adjustments are needed after this part replacement.
Verification
Perform the following steps to verify that the product is functioning as intended after this replacement:
1.) Verify that all screws removed earlier have been installed.
2.) Connect cables and Probes removed earlier.
3.) Power up the system to verify that it operates as intended.
Functional Checks
Perform the following functional checks to confirm the system is operational before returning the system
to the customer.
Table 8-92 Covers under XY / Frogleg motors installation
Steps Corresponding Graphic
1.
Thread the cover(s) on the cable.
2.
Perform a dry fit of the covers (confirm the covers face the correct way) before connecting the
cable and ground.
3.
Install the screw securing the ground.
4.
Connect the cable.
5.
Slide cover(s) into place.
6.
Re-install screws to the cover(s).
Table 8-93 Covers under XY / Frogleg motors Functional Checks
See:
Section Functional Check Debrief Script
4-2-3 Power ON/Boot Up
LOGIQ E10 Basic Service Manual, Direction
5750007-1EN, Rev. 1. Equipment passed all
required checks and is ready for use.
4-2-7 Probe/Connectors Checks
4-2-7 B-Mode Checks
4-2-7 System CFM and PWD Checks
4-2-5 Top Console checks
4-2-4 Power SHUT DOWN
