DIRECTION 5750007-1EN, REV. 1 LOGIQ E10 BASIC SERVICE MANUAL
Chapter 8 Replacement Procedures 8 - 209
NOTE: Two people are recommended for this procedure because it is very difficult for one person to
position the motor and wiggle the Top Console assembly at the same time; the second person
does not need to be a trained FE or do any lifting.
Preparation Links (if you need more information):
• 4-2-4 "Power SHUT DOWN" on page 4-9.
• 8-6-3 "Side Cover(s)/Side Air Intake (Filter) inspection / replacement" on page 8-33.
• 8-6-10 "Top Cover replacement" on page 8-55.
• 8-6-7 "Rear Cover/Air Exhaust replacement" on page 8-45
Figure 8-6 Drive Gear Assembly
Table 8-234 Preparations and Preparation Links
Preparations - you must perform the following steps
To Next Page
