DIRECTION 5750007-1EN, REV. 1 LOGIQ E10 BASIC SERVICE MANUAL
8 - 402 Section 8-15 - V Nav Roll Stand Assembling or Replacement
8-15-2 Assembling or replacing the Roll Stand (cont’d)
10.)Snap the three Rear Track Covers into place in locations shown.
Figure 8-18 Rear Track Covers Installation
