8 - 422 Section 8-16 - Options replacement
Functional Checks
Perform the following functional tests to confirm the system is operational before returning the system
to the customer.
Table 8-416 Patient I/O ECG Option replacement Functional Check
See:
Section
Functional Check Debrief Script
4-2-3 Power ON/Boot Up
LOGIQ E10 Basic Service Manual, Direction
5750007-1EN, Rev. 1. Leakage Current
measured at (record the value) and meets
allowable limits. Equipment passed all required
tests and is ready for use.
4-2-7 Probe/Connectors Checks
4-2-7 B-Mode Checks
4-2-7
PW/CW Doppler Mode Checks
use pencil probes
10-7-4 Grounding continuity
10-7-5 Chassis leakage current test
10-7-7
Isolated patient lead (source) leakage-
lead to ground
10-7-8
Isolated patient lead (source) leakage–
lead to lead
10-7-9
Isolated patient lead (sink) leakage-
isolation test
4-2-7
ECG Checks
Active ECG:
Utility -> Applications ->
Settings -> ECG -> Show ECG Tools.
Connect cables. Press Display ECG Tab
on TP. Verify ECG signal displayed on
monitor.
Plug in the ECG cables with nothing
attached so they pick up noise.
Diagnostics
4-2-7
Shear Wave Elastography (Shear Elasto)
Functional Checks, if the Shear Wave
Option was present.
4-2-4 Power SHUT DOWN
